Automatic Tank Gauge Probe ST-S

Product Overview：

It can be widely used for liquid level monitoring, measurement, and control in various tanks, pools, and vats in industries such as petroleum, chemical, pharmaceutical, and food.

Category：

Magnetostrictive Level Meter

keyword：

Magnetostrictive Level Gauge

Automatic Tank Gauge

ATG Probe

Contact Mailbox：sales@hnsanshen.com

Consult

Contact

Product Details

The ST-S magnetostrictive level gauge is a new generation of liquid level measurement sensor developed based on the magnetostrictive principle. It mainly consists of a measuring rod, an electronics housing, and a non-contact magnetic ring (float) mounted on the measuring rod. A magnetostrictive wire (waveguide) is installed inside the measuring rod. It can be widely used for liquid level monitoring, measurement, and control in various tanks, pools, and vats in industries such as petroleum, chemical, pharmaceutical, and food.

Feature

High precision

Precise measurement

316L stainless steel material, corrosion resistance

19mm thicker rod, thicker and thicker for more peace of mind

Intrinsically safe explosion-proof design

Anti-lightning, anti-radio frequency interference

Strong reliability

Long life

Stable performance

Compact structure

Strong environmental adaptability

Convenient installation

Parameter

Model	ST-S
Measurement Range	50mm~7000mm
Output Mode	RS-485 Maximum communication distance: 1200m
Power Supply	DC24V
Product Power Consumption	≤40mA
Operating Temperature	-40℃~+60℃
Measurement Accuracy	±0.5mm
Repeatability	±0.2mm
Oil Level Resolution	0.01mm
Water Level Resolution	0.01mm
Temperature Measurement Points	At least 1
Temperature Sensor Resolution	0.0625℃
Upper Blind Zone	90mm
Lower Blind Zone	50mm
Float Specifications	60*40mm
Installation Method	External mounting/Vertical pipe mounting
Explosion-proof Marking	Ex ia llB T5 Ga
Explosion-proof Certificate Number	CNV25.0142X
Associated Equipment	Zener barrier
Applicable Medium	Gasoline, kerosene, diesel, light oil, heavy oil, alcohol mixtures
Communication Address	2-digit number, supports probe addresses from 01 to 99
Protection Class	IP68
